Product Model: CDC-A3
Product Description:
1. 2 Cutting Positions-Vertical & Horizontal
2. Changable cutters for different designs
3. Minimum thickness up to 0.1mm
4. Maxmum material loss recovery
5. Low maintenance design
6. Easy programming
7. Quick loading work table system
Product Specifications:
| Working Area : |
Vertical Cutting: 100mm × 150mm Horizontal Cutting: 60mm × 160mm |
| Minimum Thickness : | Up to 0.1mm |
| Axis : | 3 Axis |
| Control System : | CNC |
| Cutter Shank Diameter : | 5.0mm |
| Accuracy : | 0.02mm |
| Spindle Motor Max. Speed : | 60,000 rpm |
| Power Supply : | 220V / 1P |
| Max Power Consumption : | 1Kw |
| Language : | English / Chinese |
| Machine Dimensions : | 620mm × 790mm × 1690mm |
| Machine Weight : | 145Kg |
| Packing Dimension/Weight : | 1410mm × 730mm × 1160mm / 200Kg |
*Our products undergo continuous improvements. This information is based on current
knowledge. We reserve the right to make changes without prior notice. Errors excepted.
