Product Model: CPC-500 EXCEL

Product Description:

1.   Uses high quality imported fiber laser source and cutting head.

2.   Stable laser output. Zero maintenance of laser source.

3.   Customized user friendly software. Able to automatically optimized the cutting paths to

      minimize the cutting time.

4.   Uses high quality servo motor for high accuracy cutting.

5.   Auto-tracking focusing. When cutting of uneven work piece, the system is able to track

      and anto focus the laser for accurate and even cutting.

6.   Auto-feed cutting for roll material.

7.   Rotary cutting for bangles and rings.

8.   Highly efficient material lost retrival system design.

Product Specifications:

Laser source :	Imported Fiber Laser
Cutting area :	300mm × 300mm
Cutting thickness :	Maximum 3.0mm (Depending on material)
Cutting line width :	0.04 ~0.06mm
Cutting speed :	600 ~ 1500mm/min
Cutting accuracy :	0.01mm
Cooling mode :	Air cooled
Cutting air pressure requirement :	8 ~ 12 bar (oil-less compressor with   compressed air dryer)
Maximum power consumption :	3Kw / 5Kw
Power supply :	220V / 1P
Machine dimension :	980mm × 960mm × 1730mm
Packing dimension :	1110mm × 1200mm × 1850mm
Weight :	320Kg (Net) / 400Kg (Gross)
Options :	Dust collector

*Our products undergo continuous improvements. This information is based on current

knowledge. We reserve the right to make changes without prior notice.
