Product Description:
1. Uses high quality imported UV laser source
2. Fully enclosed air-cooled laser system
3. Built-in computer system with WINDOWS based software.
4. Marking software is compatible with most picture formats like AL, PLT, DXF, BMP, JPEG etc
5. Able to mark on all metal and non-metal materials
6. Internal marking even for thickness of 2.0mm
Product Specifications:
|
Laser Type :
|
UV Laser
|
|
Laser Power :
|
3W
|
|
Laser Wavelength :
|
355nm
|
|
Beam Quality :
|
1.2M2
|
|
Minimum Line Width :
|
0.01mm
|
|
Marking Area :
|
50×50mm (Standard)
100×100mm (Optional)
|
|
Cooling System :
|
Air Cool
|
|
Marking Table :
|
X , Y and motorized Z axis
|
|
Marking Depth :
|
Up to 2.0mm
|
|
Max Power Consumption :
|
1.5KW
|
|
Power Supply :
|
220V/ 1P/ 50-60H
|
|
Machine Dimensions(L×W×H) :
|
700×900×1400 (mm)
|
|
Packing Dimension :
|
800×1000×1450 (mm)
|
|
Weight, Nett / Gross :
|
110 / 130Kg
|
*Our products undergo continuous improvements. This information is based on current
knowledge. We reserve the right to make changes without prior notice. Errors excepted.
